CarSim

Quick Start Guide

Version 8.2

Mechanical Simulation

Table of Contents
1. Introduction .....................................................................3
2. Viewing CarSim Results..................................................4
Start CarSim ................................................................................ 4
Go to the CarSim Quick Start Dataset .......................................... 5
The CarSim Run Control (Home) Window Layout ....................... 8
Visualize a Simulated Test ........................................................... 9
View Plots ................................................................................. 12
View Model Information............................................................ 15

3. Making New Runs ......................................................... 17

Make a New Database................................................................ 17
Run a Simulation ....................................................................... 20
Run with a Different Vehicle Speed ........................................... 21

4. Making New Vehicles.................................................... 26

Create a Modified Vehicle.......................................................... 26
Navigate the CarSim Database ................................................... 34
Create a Vehicle with Shared Datasets ....................................... 38

5. Managing Data .............................................................. 43

Make a New Plot Dataset ........................................................... 43
Add a Plot to a Procedure Dataset .............................................. 47
Copy Data from One Database to Another.................................. 48
Look at a Configurable Function ................................................ 55
View a Vehicle with Payloads .................................................... 58
Browse the Installed Database.................................................... 60

6. Learning More About CarSim........................................ 61

CarSim Help System.................................................................. 61
Math Model Documentation....................................................... 63
The CarSim Web Site................................................................. 66
What to Read Next..................................................................... 67

NOTICE

This manual describes software that is furnished under a license agreement and may be used or
copied only in accordance with the terms of such agreement. BikeSim, CarSim, TruckSim,
VehSim, and VehicleSim are registered trademarks of Mechanical Simulation Corporation.
1996 2013, Mechanical Simulation Corporation.
Last updated February 2013
ii

1. Introduction
This guide will introduce you to CarSim 8.2. It shows the basics for simulating tests, viewing
results, and making changes to the vehicle and test procedure.
No experience with using the software is assumed. If you have used versions of CarSim older
than version 8.2, we recommend that you work through this guide you will probably pick up
some new capabilities regarding the basic use of the software.
If you are involved with teaching others to use CarSim, then we strongly recommend that you go
through this guide. CarSim 8.2 has new capabilities intended to support occasional users.

What You Will Learn

High-fidelity simulation of vehicle dynamics requires extensive data. CarSim includes a database
with many example vehicles and test procedures. If you are new to CarSim, the GUI and database
will not be familiar at first. This guide is organized to introduce the major elements of the GUI
and database so that you will be aware of the major features in CarSim. When you complete the
guide, you should be familiar with the CarSim organization and basic tools.
The steps in this guide follow a simple tutorial that you should follow in sequence. If you do this,
the figures in this guide should match the windows you see in CarSim. Working through this
guide will not take long typically less than 90 minutes.
It is not necessary to master every option and feature in CarSim during this tutorial CarSim
has extensive on-line help that you can use later on to refresh your memory.

Before You Start

Before starting, there are just a few requirements.
1.

CarSim must be installed on your computer. If you have not yet installed CarSim, log into
your
computer
as
an
administrator,
launch
the
installation
program
Setup_CarSim_8.2.exe, and follow the instructions.

2.

You must have a license key to run CarSim, as described during the installation.

3.

You will need to know the location of a file named CarSim82_Quick_Start.cpar.

Note

The CPAR file is in a folder [CarSim_Prog_Folder]\Resources\

Import_Examples, where [CarSim_Prog_Folder] is a location that
was specified when the software was installed on your computer.
If you are not sure where the CarSim programs are installed, you can
right-click on the CarSim item in your Windows Start menu and view the
properties. Another option for finding the CPAR file is to use Windows
to search for the file CarSim82_Quick_Start.cpar.

2. Viewing CarSim Results

Lets start by viewing some of the simulation results generated by CarSim. When you start
making new simulation runs, you will use the same methods to view your new results.

Start CarSim
1.

Start CarSim by using the Start menu shortcut: Programs->CarSim 8.2->CarSim or by

double-clicking a CarSim icon on your desktop.
When CarSim starts, it brings up a dialog box to select a database (Figure 1). If you have
just installed CarSim for the first time, there will be only one database shown.

Figure 1: Open the database from the CarSim installation.

For the purpose of this tutorial, do not check the box to skip this window

Choose the example database that was installed with CarSim and click the button Continue
with the selected database .
Alert

The first time you launch CarSim, a License Settings window will pop
up (Figure 2). Click the Select button
to continue launching CarSim.
Note the checkbox with the caption: Dont show this window when
starting
. If you are using a network license, do not check this box;
you may need to select different license features in the future.

CarSim opens with a view of the most recently visited data screen. The first time CarSim is
opened after installation, this will be the CarSim Run Control screen (Home, Figure 3).

Chapter 2

Viewing CarSim Results

Figure 2. Popup window with license settings.

Figure 3. The CarSim Run Control (Home) screen.

Go to the CarSim Quick Start Dataset

1.

For the purpose of this tutorial, use the View menu to make sure options are set to Show
Button Toolbar, Show Button Labels, and Show Sidebar (Figure 4).

Figure 4. The View menu.

Chapter 2

Viewing CarSim Results

Use the View menu to set the window size to match common settings in Windows. Small
size is standard (text is sized at 100%); medium matches when text is set to 125%; large fills
your screen.
2.

Click the Home button

shown in Figure 3.
Note

to view the main CarSim window similar in layout to the one

In CarSim documentation, the word dataset refers to the contents of a

single file containing data. Whenever you are viewing a CarSim window,
you are seeing the contents of a single dataset. For example, when
viewing the CarSim Run Control screen you are seeing a dataset for
setting up a simulation run. You will soon see that this can include
numerical values and links to other datasets.
A library is a collection of datasets that share a common screen
configuration for a common type of data. For example, CarSim Run
Control is a library containing datasets, with each representing a
different simulation run.
A category is an additional organizational tool, used to group related
datasets within a library. In the case of the baseline dataset shown in
Figure 3, the category is * * Quick Start Guide Example and the
dataset is named Baseline.

3.

Look at the CarSim window title. If it ends with the category and name {* * Quick Start
(Figure 3), then you are looking at the right dataset; please continue
Guide} Baseline
with step 3. Otherwise, use the Datasets menu (Figure 5) to show all of the datasets in this
library. Select the dataset * * Quick Start Guide Example -> Baseline. After you make this
selection, the screen should appear much like Figure 3.

Figure 5. Use the Datasets menu to find the Quick Start Guide Example.
Alert

If you or someone else has been using the CarSim database, there is a
small chance that the Quick Start Guide Baseline dataset does not exist.
In this unlikely case, follow the instructions in the first two sections in
the next chapter to make a database with this Baseline example (these are
sections Make a New Database and Run a Simulation, starting on page
17). Then return here to follow the steps for viewing simulation results.

Chapter 2

4.

Viewing CarSim Results

Right-click and hold on the Help button

for a tool tip (Figure 6).

Figure 6. Right-click and hold for information about a button or other control.
Note

5.

The right mouse button is used throughout CarSim to obtain tool tips.
Right-click and hold on buttons, fields, and various control objects to
obtain short summaries of their functions.

Click the Help button. This launches the Adobe Reader program with a PDF documentation
file for the current screen (Figure 7).

Figure 7. Documentation about the current screen.

At any time, the documentation for the current screen can be obtained with this button or by
typing the F1 key. The Help menu can also be used to access many volumes of
documentation installed with CarSim.
Notes All of the PDF documents in CarSim that are more than a few pages in
length include bookmarks for rapid access to sections of interest. For

Chapter 2

Viewing CarSim Results

example, Figure 7 shows the bookmarks for the Run Control Screen
document
. Click on a topic such as Results (Post Processing)
to
jump to that section of the document.
After you have gone through this tutorial, you can return to the documentation for the Run
Control screen. For now, close the PDF window.
Review You have adjusted the appearance of the CarSim window and gone to a
dataset that you will use in this tutorial. You have seen built-in help
available by right-clicking, typing F1, using the Help button, and using
the Help menu.

The CarSim Run Control (Home) Window Layout

The CarSim Run Control screen is the starting point to access the main tools and datasets in
CarSim (Figure 8).

Figure 8. Layout of the CarSim Run Control screen.

The blue boxes on the screen are hyperlinks to more data, similar to links shown on web pages.
The main part of the screen is divided into three sections. The left column, titled Test
Specifications, has a blue link to the vehicle data to be used in the simulation, and at least one
blue link to a dataset that defines the test procedure.

Chapter 2

Viewing CarSim Results

The middle column has controls for running the math models. Later on, you will use the button
here to perform new simulations.
The right column, titled Results (Post Processing), provides access to tools you will start using
in the next section to evaluate the simulation run.

Visualize a Simulated Test

In this section, you will use the animator in CarSim to visualize simulated test results.
1.

Right-click on the Animate button on the CarSim Run Control screen for the button tool
tip. Then click the Animate button. VS Visualizer (the animation tool in CarSim) will show
an animation of the run (Figure 9).

Figure 9. A VS Visualizer window.

2.

VS Visualizer combines the results of a simulated test with a simulated video camera. Click
and hold mouse buttons in the animation display region and use simple sweeping motions to
move the simulated camera:
a. Sweep (left, right, up, down) while pressing the right mouse button to circle around
the vehicle.
b. Sweep up and down while pressing both the left and right mouse buttons to move the
camera closer or further away from the vehicle. (If you have a middle mouse button,
you can press this to accomplish the same thing.)
c. Press the shift key while pressing the right mouse button in the viewing area; sweep
in any direction to drag the viewing area. This changes the aim of the camera. Once

Chapter 2

Viewing CarSim Results

you move the mouse, a view of the current axis directions appears with a box at the
center of the viewing area (Figure 10).

Figure 10. View of the axes origin and direction when shift-dragging.
d. Go to the Help menu and select the item Help with mouse/keyboard controls or
press the F1 key. This brings up a window showing all of the controls affecting the
camera (Figure 11). Close the window after reviewing the contents.

Figure 11. Mouse controls for the VS Visualizer camera.

3.

Notice the slider at the bottom of the screen

(Figure 12). If the slider shown in the figure
is not visible in your window, select the View menu item Time Control to display it. As the
animation runs, the slider moves from left to right. The current time (e.g., 3.202 s) is also
shown . The animator has controls for starting, stopping, and jumping to any point in the
simulated run.
a. If the animation is paused, play it by clicking the play/pause button
or pressing
the space key on your keyboard. (If the spacebar does not work, click in the
animation area with the left mouse button to ensure it is active.)
b. If the animation is playing, pause it by clicking the play/pause button
the space key on your keyboard.

10

or pressing

Chapter 2

Viewing CarSim Results

Figure 12. More controls for VS Visualizer.

c. When the animator is paused, move the slider

to locate any point in the run.

d. When the animator is paused, use the or keys to move the slider forward or
backward in the animation (this accomplishes a very slow motion).
4.

The playback speed is normally real-time. However, you can control the speed interactively
with additional time controls. Right-click on the bottom part of the screen for a drop-down
list of controls (
in Figure 12) or use the View menu to show the Time Multiplier
controls. The figure shows the bottom of the window with the time multiplier visible.
a. Move the time multiplier slider
left and right to adjust the time scale (shown in
the field
). This ranges from fast-forward (far right) to fast-reverse (far left) to
slow motion (middle of the scale). If your mouse has the middle scroll wheel, this
will also work.
b. Move the jog/shuttle slider
left and right to temporarily adjust the speed. When
you release the control, the animation goes back to current time scale setting .
c. Restore the speed to 1x (real time)

. The direction (forward/reverse) is unaffected.

d. Reverse the direction (forward/reverse) with this shortcut button

5.

VS Visualizer normally renders scenes with 3D objects whose shapes are defined by sets of
polygons. To see the polygon edges, left-click anywhere in the 3D view to make it active,
then type Ctrl+W repeatedly to cycle through several viewing modes (Figure 13).

6.

Exit VS Visualizer by clicking the X button in the upper-right corner of the window or by
typing Alt+F4. You should once again be viewing the CarSim Run Control screen (it may
have been hidden in the background).
Review You have now gone through the main interactive controls for using VS
Visualizer. The following sections assume you are comfortable
manipulating the view and working with VS Visualizer. For more
complete reference information, use the CarSim Help menu and select
the VS Visualizer reference manual from the Reference Manuals
submenu.

11

Chapter 2

Viewing CarSim Results

Figure 13. A view showing solid shapes plus wireframes.

View Plots
Although VS Visualizer offers a quick way to see a simulated test, the plotter is the tool most
frequently used to study the vehicle behavior. The plotter in CarSim is called WinEP (Windows
Engineering Plotter).
1.

From the same Run Control screen, click the Plot button. In a few seconds, the WinEP
window will appear showing plots for variables of interest for the double lane-change
procedure (Figure 14).

2.

If this is the first time the plotter has been run on this computer, make some optional
adjustments for better viewing.

3.

a.

Check to see if the toolbar is visible (Figure 15). If the toolbar is not visible, show it
using the View menu.

b.

If the plot window is small, enlarge by double-clicking the title bar or clicking the
zoom box in the upper-right corner of the window, then click a tile button
, or
select a Tile option from the Window menu. After you exit the plotter, it will open in
the new layout the next time.

Each individual sub-window can be moved or re-sized as desired. Zoom in on any of the
plot windows by double clicking in the title. For example, expand the first plot: Lateral
Tracking vs. Station (Figure 16).

12

Chapter 2

Viewing CarSim Results

Figure 14. The initial appearance of multiple plots in WinEP.

Figure 15. Toolbar for WinEP.

Figure 16. View one of the plots.

13

Chapter 2

Viewing CarSim Results

Press the Page-Down key to cycle through the open plots. Other options for controlling and
navigating among the windows are provided under the Window menu.
This example has nine plots; all are useful in evaluating the performance of the vehicle.
Look briefly at each. Later in this guide, you will see that hundreds of variables are
produced by the CarSim math models and can be easily plotted.
4.

To view a portion of any plot in more detail, click and hold the left mouse button in the plot
area and drag to create a rectangle. When you release the button, the plot will be re-drawn to
show the region you selected.

5.

To restore the original scaling, type Ctrl+R (a shortcut for the Format menu item Redraw
Original Scale). Alternatively, click the toolbar button
.

6.

The plotter can show the numerical X and Y values for any point in any plot.
a. Type Ctrl+D (a shortcut for the Data menu item Show Data Points), or, click the
toolbar button
. A cross-hair cursor appears on the first point in the first plot in the
active window.
Note

The cross-hair cursor is initially at the left edge of the plot area (the X-Y
axis origin). Because it lines up with the vertical and horizontal axes, it is
hard to see until it has been moved.

The values of the X and Y variables are shown in the status bar (the strip at the
bottom of the window) .
The cursor position
is controlled by key presses or by selecting an item from the
Data menu (under the sub-menu Cursor Position Info). Although the menu is
functional, it is mainly used as a form of built-in documentation for reminding you
which keys can be used to control the cursor.
b. Move the cursor to the right using the key. Move it more quickly using the Shift
key and key together (Shift+). Move it even more quickly using Ctrl+Shift+.
To move to the left, use , Shift+, and Ctrl+Shift+. There are also buttons in
the toolbar for moving the cursor in several increments:

c. To move the cursor to a different pair of variables in the same plot (assuming the plot
has an overlay of two or more sets of data), hit the Tab key, or click the toolbar
button
.
d. Use the Home and End keys to jump to the beginning and end of the plot. Or, use the
toolbar buttons
and
.
e. Use the - and keys to jump to the maximum and minimum values. Or, use the
toolbar buttons
and
.

14

Chapter 2

Viewing CarSim Results

7. Exit WinEP to return to the CarSim Run Control screen.

Review You have now gone through the main interactive controls for using the
plotter. The following sections assume you are comfortable zooming
and viewing numerical values using the cross-hair cursor. For more
complete reference information, use the CarSim Help menu and access
the Plotter reference manual (in the Reference Manuals submenu).

View Model Information

On the CarSim Run Control screen, there is a View button
(Figure 17) in the lower-right
corner of the screen that provides access to a number of machine-generated documents that
describe technical details about the math models.

Figure 17. View button in the lower-right corner of the CarSim Run Control screen.
1.

next to the View button and select the first item Echo file with
Use the drop-down list
initial conditions
. Then click the View button
to display the file in a text editor
(Figure 18).

2.

Scroll through this Echo file in the editor. Note that it is organized into several sections,
going from top to bottom:
a. The top of the file has System Parameters that exist in any CarSim model. These
include the time step, start time, stop time, etc. The format of the file is described in
the reference manual for VS Commands and the VS Solver Programs, accessed from
the Help menu. The parameters are listed in alphabetical order.
b. The next section has Model Parameters (dimensions, masses, coefficients, etc.).

15

Chapter 2

Viewing CarSim Results

Figure 18. Echo file generated for a simulation run.

c. The file next lists all of the Configurable Function (tabular) data, used to describe
nonlinear properties of the vehicle such as the suspensions and tires, and to specify
some of the control inputs.
d. Go to the end of the file, and see that it contains about 5000 lines (approximately 80
pages when printed).
e. Exit the text editor (Alt+F4).
The Echo file is generated by a VS Solver (the part of CarSim that performs the math model
calculations) to document all of the properties of the math model that were used in the
simulation run. This file is the ultimate documentation for the math model capabilities that
were pertinent for the run.
In general, you will read these files but not modify them. There are methods to use Echo
files as inputs to the math model, but this is an advanced topic beyond the scope of this
guide.
Review You have now used buttons on the right-hand side of the Run Control
screen to view outputs from a CarSim math model; Animate, Plot, and
View. You interacted with VS Visualizer and WinEP the main tools
in CarSim for viewing results.

16

3. Making New Runs

As you go through this chapter, you will make some new runs in CarSim. But first, you will
create a new database in which to experiment, without risk of corrupting the original installed
database.

Make a New Database

1.

If CarSim is still running, then select the File menu item New Database from a
Consolidated Parsfile (this is the second item from the top), and proceed to step 2.
If CarSim is not running, start it by using the Start menu shortcut: Programs->CarSim 8.2
->CarSim or by double-clicking a CarSim icon on your desktop.
When CarSim starts, it brings up the dialog box you saw before (in Chapter 2) to select a
database (Figure 19). This time, you will not use an existing database. Instead, click the
and proceed to step 2.
button to create a new database

Figure 19: Create a new database for use with this Quick Start Guide.
2.

A window will pop up describing the next steps to be taken to create a new database from
the consolidated parsfile. Read the message and click Continue. You will then be given the
Windows file browser to locate a consolidated parsfile (extension CPAR, Figure 20). Locate
the file for this quick start guide: CarSim82_Quick_Start.cpar and click the Load
button to continue.
Note

As noted in the Introduction, this file is located in the same folder that
has the CarSim programs. See page 3 for tips on finding this file if you
dont know where it is.

17

Chapter 3

Making New Runs

Figure 20. Locate the CarSim Quick Start CPAR file.

If you were already running in CarSim (that is, you selected the File menu item New
Database from a Consolidated Parsfile in step 1), you will be given a choice to use the
Same Window or a New Window. If given this choice, choose Same Window.
3.

The Windows file browser will be shown again, prompting you make an empty folder for a
new CarSim database (Figure 21). To do this:

Figure 21. Select an empty folder for a new database.

a. Navigate to a place on your hard drive for the new CarSim database folder. This
must be a location where you have read/write permission.

18

Chapter 3

Making New Runs

b. Click the button Make New Folder

c. The new folder will be highlighted with a name such as New Folder. While it is
highlighted, you can type a new name. Give it a suitable name, such as
CarSim_Data_QS
. Warning: at this point, be careful not to click the New
Folder button again, or press the Enter key with the New Folder button selected (you
dont want to create a second new folder!). Carefully click the OK button
to
continue.
A terminal window will pop up briefly listing files that are being copied. It will quickly
disappear.
Alert

If your installation is set to show the License Settings window when

launching CarSim, you will once again see a license summary window
(Figure 22). If you are running with a network license server, click the
Select button
to continue. There is a checkbox to skip the display of
this window that you might want to set
; do not check this if you are
using a network license because you might need to select different
license options in the future.

Figure 22. Window showing license settings.

CarSim will take a minute or two to create the new database. When it completes, you should
be looking at the Run Control screen for the Quick Start Guide (Figure 23). This is similar
in appearance to the dataset you saw in Chapter 2.

Figure 23. Appearance of CarSim Run Control Screen when first created from the CPAR file.
Notice that the Animate and Plot buttons are dimmed. This is because the simulation output
files are not included in the CPAR file that you used to create this new database. Until you
run a simulation, there are no results to view. Also, notice that the Run Math Model button

19

Chapter 3

Making New Runs

is dimmed. This is because the dataset is locked. (All datasets in a new database are always
initially locked.)
Review You have just gone through the steps needed to create a clean database
with only the data needed for the instructions that follow in this Quick
Start Guide.
The steps you have just taken for creating a new database are useful for
creating a clean database when starting a major new project; it is not
necessary to repeat these steps for everyday use of CarSim.

Run a Simulation
You should still be viewing the locked CarSim Run Control screen for the single example
simulation in your new database (Figure 23).
1.

Click the Lock button

(Figure 24) to unlock this Run Control dataset. Notice that many
of the controls are now active, including the Run Math Model button .

Figure 24. Run Control screen when unlocked.

2.

Right-click and hold on the Run Math Model button

that you can always get tool tips in CarSim this way.

for a tool tip for this button. Recall

3.

Click the Run Math Model button to make your first run. A status bar appears to show the
progress of the run (Figure 25). The CarSim math model runs significantly faster than real
time, so this will take just a few seconds.
When the run is complete, the progress bar disappears (Figure 26). Now that there are
simulation results to view, the Animate
and Plot
buttons are active. (If these buttons
are still dimmed, click the refresh button .)

3.

Click the Animate button to confirm that the simulation operated as intended. Close VS
Visualizer when done.

20

Chapter 3

Making New Runs

Figure 25. Progress bar that is displayed when the math model is running.

Figure 26. The Animate and Plot buttons are active after a run is made.
Review You have just made your first simulation run in CarSim from the Run
Control screen. You will make many more the fun is just getting
started!

Run with a Different Vehicle Speed

You should be viewing the CarSim Run Control screen with the dataset named Baseline in the
category * * Quick Start Guide Example (Figure 26).
You will change the speed for the simulated test using this main screen.
1.

Right-click the Duplicate button

duplicate the current dataset.

for the tool tip information. Then click the button to

The menu bar and tool bar will be covered with a window that prompts you to enter a title
for the new dataset (Figure 27). Enter a new name in the title field: My New Test
. Click
the Set button
to set the new name. The new screen display is nearly identical to the
previous one. Initially the main difference is that the CarSim window has the new name in
the title ( , Figure 28). You will now make additional changes as shown in Figure 28.

21

Chapter 3

Making New Runs

Figure 27. Setting the name of a new dataset.

Figure 28. The new Run Control dataset (after the speed is set).
2.

Check the box to show more options

. More controls will appear in the bottom part of the
screen, including another checkbox to override driver controls .

3.

Check the box to override driver controls

for vehicle speed .

4.

Use the drop-down control for choosing a method for controlling vehicle speed and select
the option Constant target speed
. A yellow field appears next to the control
. Enter
the value 150.
Note

. This will show more controls, including one

The blue link to a procedure dataset has a title that implies the test speed
is 120 km/h . Because the override controls appear in the dataset after
the blue link, this speed will override the value specified in the linked
dataset. This section of the Run Control screen provides convenient
controls to temporarily modify a procedure without permanently
changing it.

22

Chapter 3

Making New Runs

5.

The Notes yellow field

has text content from the original baseline Run Control dataset
that was copied. Edit this text to indicate that you have made changes.

6.

Click the Run Math Model button. As before, a status bar shows the progress of the run.

7.

When the run is complete, the Animate and Plot buttons should become active. However, if
they remain dimmed, click the Refresh button
. Click the Animate button to view the
new simulated behavior with VS Visualizer. After viewing the results, close VS Visualizer.

8.

On the lower-right corner of the screen, right-click the checkbox Overlay animations and
(Figure 29) to read the tool tip, and then check the box. When
plots with other runs
checked, results of multiple runs can be overlaid; potential links appear for selecting runs to
overlay.

Figure 29. Overlay a new run with the Baseline run.

9.

Press the drop-down control

to select an existing run to overlay. Choose Baseline
(from the submenu * * Quick Start Guide Example). The screen should now show a blue
link (Figure 30).

Figure 30. Screen appearance when set to overlay results with the Baseline run.
10. Next to the Animate button, right-click the checkbox Set run color
(Figure 31). The
tool tip indicates the vehicle color can be set here; check the box to reveal a color selector
.
11. Press the color selector button
yellow .

to display a color palette (Figure 32). For example, choose

23

Chapter 3

Making New Runs

Figure 31. Option to set a run color.

Figure 32. Color selector palette.

Note

The new color affects the display in VS Visualizer. It does not affect
images in the CarSim GUI; for example, the image shown at the bottom
of the screen (Figure 30) will not change. The image on the Run Control
screen matches an image associated with the vehicle dataset contained
elsewhere in the database that uses the default color of the 3D object.

12. Click the Animate button to view both runs in VS Visualizer (Figure 33). After viewing the
results, close VS Visualizer.
13. Use the Datasets menu

(Figure 34) to return to the Baseline run

24

Chapter 3

Making New Runs

Figure 33. Animation with overlay of two runs.

Figure 34. Use the Datasets menu to return to the Baseline dataset.
Review In this chapter you created a new database for running through the
instructions in this Quick Start Guide. You ran simulations with two
vehicle speeds and overlaid results in VS Visualizer.
The method used in this section of setting test conditions from the Run
Control screen is often used to make quick variations of existing test
procedures. Later on, you will go into the procedure part of the
database to modify the procedure so it can be applied automatically to
future runs.

25

4. Making New Vehicles

In the previous chapter, you created a Quick Start project database and ran two simulations. In
this chapter, you will make datasets that describe variants of the baseline vehicle and run
simulations with those variants. In doing so, you will learn some things about the CarSim
database design and some of the tools available for navigating among datasets.

Create a Modified Vehicle

Continue from the previous section, viewing the Run Control screen with the dataset Baseline.
1.

Click the Duplicate button

(Figure 35) to copy the current run dataset. When prompted,
enter a new name: Modified Vehicle #1 and click the Set button. Note that the Animate and
Plot buttons are dimmed; this is because the simulation has not been made yet.

Figure 35. Run Control Screen for Modified Vehicle #1.

2.

Links for datasets are shown in CarSim with hypertext labels with blue backgrounds.
a.

Hover the mouse over the blue link for the vehicle
underlined, as done on many web pages.

b.

Click on the underlined text to view the linked dataset in the CarSim window. After
clicking on the vehicle link, you should see the Vehicle: Assembly dataset in the
window (Figure 36). The vehicle used for the baseline run is named C-Class,
Hatchback 2012.
Note

and see that the text is

The Quick Start database initially contains this single vehicle description.
It is possible to make many runs involving this vehicle. It is also possible
to modify the vehicle properties. However, this Vehicle Assembly
dataset is already shared with two existing simulation runs, so if the
vehicle is modified and the existing simulations are re-run, then different
results will be obtained because the vehicle has been changed.

26

Chapter 4

Making New Vehicles

Figure 36. The original baseline Vehicle Assembly dataset.

To avoid this potential problem, you will now make a completely new
independent vehicle description that can be modified to create a variant.
The original vehicle description is still available to make new
simulations that might be needed for future comparisons with the original
baseline reference.
3.

Select the File menu item New Dataset Plus All Linked Datasets (Figure 37). You will be
prompted to specify a category for new datasets that are about to be created (Figure 38).
Enter Modification #1 as shown, and then click the New datasets button. A pop-up
window will appear while CarSim is working; when the datasets are all copied another popup window will report how many datasets were duplicated (Figure 39).

Figure 37. Duplicate a dataset plus all links.

27

Chapter 4

Making New Vehicles

Figure 38. Specify a category for new datasets.

Figure 39. Result after new datasets were created and added to the database.
4.

The duplicated Vehicle Assembly screen has the same notes and blue links, but there are
changes in appearance (Figure 40):

Figure 40. Duplicated Vehicle Assembly dataset.

a. The category name shown in the title is now Modification #1
had the category name CS C-Class).

. (The original dataset

b. The image of the hatchback is gone, replaced by a generic vehicle icon

c. If you right-click on any of the blue links, the tool tip indicates that the category of the
linked dataset is Modification #1 .

28

Chapter 4

Making New Vehicles

Click on the blue link for the sprung mass

mass data (Figure 41).

(Figure 40) to view the duplicated sprung

Figure 41. Duplicated Vehicle Sprung Mass dataset.

5.

The duplicated sprung mass screen has the new category name Modification #1

Right click on one of the two data fields showing the height of the rear wheel centers above
to view information about this
the origin of the sprung mass coordinate system
parameter. Change the values for both heights for the rear wheels to 100. This change
means the wheels are lowered relative to the sprung mass. Or, from the point of view of the
wheels, the sprung mass will be lifted at the rear axle.
Notice that the Undo button is now active
. Thats because youve modified the new
sprung-mass dataset. Click the Undo button (or type the Windows shortcut: Ctrl+Z) and see
the changes revert. When there are no more changes to undo, the button is dimmed again.
Once youve clicked Undo, the Redo button becomes active . Click Redo to restore your
changes (or use the shortcut Ctrl+Y). After youve restored all changes by repeated clicking
of the Redo button, it will be dimmed again as shown in the figure.
6.

Click the Back button

to return to the Vehicle Assembly screen. This button is similar to
the Back button in a web browser. When you go to a dataset by clicking on a blue hyperlink
(e.g., to get from the Vehicle Assembly screen to the Vehicle Sprung Mass screen), you
can return to the previously viewed screen using the Back button.
Click the Back button once more to return to the Run Control screen, where you will once
again be viewing the Run Control dataset named Modified Vehicle #1 that you created in
step 1 (shown again in Figure 42).

29

Chapter 4

Making New Vehicles

Figure 42. Choose the new vehicle for the Modified Vehicle simulation.
Note

7.

The Run Control dataset is still linked to the original vehicle. The New
Dataset Plus All Linked Datasets creates new datasets, but does not
modify any existing datasets. Links to the original dataset remain intact
until modified manually, as you will do in the next step.

Press the mouse button on the drop-down control adjacent to the blue link for the vehicle
. CarSim shows a menu of all of the datasets in the linked library (the Vehicle
Assembly library). Choose the vehicle from the category submenu Modification #1.
You have now changed the vehicle associated with this simulation setup from the original
baseline to the vehicle with the modified sprung mass properties.
Note

8.

You might notice that the image of the vehicle on the bottom of the Run
Control screen has disappeared. This is because the image on the
Vehicle Assembly screen was replaced with a generic vehicle icon
(Figure 40) when the vehicle and all linked datasets were duplicated. The
process of restoring the image is not complicated and is described in the
VS Browser (GUI and Database) reference manual, available from the
Help menu.

Make a few cosmetic changes to identify this simulation run:

a. Edit the Notes text

to identify whats different about this run.

b. Change the run color to red

9.

to identify the modified vehicle in animations.

Click the Run Math Model button to run the simulation with the new vehicle.

10. Click the Animate button to view the results (Figure 43). Right-click and drag horizontally
to see the side view of the vehicle, and confirm that the changes made to the wheel locations
relative to the sprung mass took effect. Close VS Visualizer.
11. Compare the motions of the modified vehicle to those of the original.

30

Chapter 4

Making New Vehicles

Figure 43. Animation of the vehicle lifted at the rear.

a.

Check the box Overlay animations and plots with other runs

(Figure 44).

Figure 44. Controls for overlaying simulation results from multiple runs.
b. Use the drop-down control

to choose the run named Baseline

c. Click the Animate button to view the simulation results from the two tests. When
finished, close VS Visualizer.
d. Click the Plot button to view plots of some variables of interest. For example, look at
the plot of roll angle (Figure 45). As you might expect, raising the sprung mass results in
the vehicle rolling a little bit more during the maneuver.
When finished, close WinEP.

31

Chapter 4

Making New Vehicles

Figure 45. Effect of raising the sprung mass on vehicle roll during the double lane change.

12. Compare the text Echo files for the two runs.
a. If necessary, use the drop-down control
conditions.
b. Click the View button

(Figure 44) to select Echo file with initial

to view the Echo file generated for the lifted vehicle.

c. With the text editor showing the Echo file, find the CarSim window (it might be behind
the text editor window).
d. Click on the blue link for Baseline. You should now view the Run Control dataset for
this run.
e. Use the View button and adjacent drop-down control to view the Echo file for this Run
Control example, as well. The text editor should be showing the Echo file for Baseline,
with a tab to access the other file (Figure 46).

32

Chapter 4

Making New Vehicles

Figure 46. Using the ConTEXT text editor to view Echo files.
f.

Select the Tools menu item Compare. This brings up a dialog box (Figure 47). Use the
and
) and then click
controls to set each file name to the two files that are open (
the Compare button
. This displays a comparison window with differences in the
files highlighted in yellow (Figure 48).

Figure 47. Setting ConTEXT to compare two files.

g. Use the Next and Previous arrow buttons
to jump to the differences in the files. You
should see that only a few lines differ, with the ones affecting the vehicle dynamics
being the heights of the rear wheel centers that were changed from 325 mm to 100 mm.

33

Chapter 4

Making New Vehicles

Figure 48. Comparison of two Echo files.

h. Click the Next arrow button
a few more times. You should also see differences in a
few calculated properties (the descriptions include the notation CALC) that depend on
the equilibrium height, such as the CG height for the entire vehicle, and the moments of
inertia for the entire vehicle. Close the ConTEXT (text editor) windows when you are
through.
Review You have now made three runs in the new Quick Start database: the
original baseline, a run with the original vehicle but at a higher test
speed of 150 km/h, and a modified vehicle, running at the original 120
km/h.
You viewed the differences in vehicle behavior with the aid of
animation and by comparing plots of vehicle response variables such
as roll angle.
You used the ConTEXT text editor to compare the full datasets
associated with the simulations and confirmed that only two input
parameters were different. You might also have seen differences in
calculated properties and initial conditions that were affected by those
two parameters.

Navigate the CarSim Database

You have seen that the full description of a simulated test combines datasets for a vehicle,
controls, road conditions, etc. (Figure 49). The vehicle dataset in turn combines data from parts
such as the sprung mass, tires, powertrain, etc.
Building a vehicle is done in the software by linking to subsystems and parts from the database.
Conceptually, this is similar to building a physical vehicle from existing systems and parts from
warehouses. Just as the same type of tire might be used on all four wheels of a physical vehicle,
the same tire dataset can be use for all four wheels of the simulated vehicle.

34

Chapter 4

Making New Vehicles

Figure 49. Simulation runs are assembled from datasets selected from libraries.
In the previous section, you navigated between three screens and compared the text files
generated for the simulation run named Baseline and the one named Modified Vehicle #1. In this
section, you will learn about more navigation tools to quickly view any vehicle components of
interest that are used in a simulated test.
1.

Use the Datasets menu to navigate to the Modified Vehicle #1 dataset

(Figure 50).

Figure 50. CarSim navigation buttons.

So far, you have navigated by using the Datasets menu
, by clicking on blue data links
, and by using the Back button . CarSim has other tools for navigating.
2.

The five buttons at the far left of the button bar all involve navigation. Right-click on each to
see the tool tip.
a.

The Forward
button undoes the most recent Back action. To test this, click Back
and then click Forward
to return to the view shown in the figure.

b.

Click Previous
to return.

to change datasets in the Run Control library, and then click Next

35

Chapter 4

c.
3.

Making New Vehicles

Click on the vehicle blue data link

to view data in a different library, and then click
Home
to return to the Run Control library.

The Go To menu
(Figure 51) has commands that duplicate the functions of the Back,
Forward, Previous, and Next buttons. Most commands have keyboard shortcuts for the
commands involving the PgUp and PgDown keys that you can use to quickly view recent
datasets. The menu also has a submenu showing the recently viewed datasets
. For
example, a vehicle sprung mass dataset should be on the menu; select it. After confirming
that the view has changed, return by clicking the Home button .

Figure 51. The Go To Menu has navigation controls.

4.

The Libraries menu lists all libraries in CarSim (over 200). If you select one, it goes to that
library and shows the most recently viewed dataset. This first one is Home: CarSim Run
Control with a keyword shortcut of Ctrl+H.

5.

The lower part of the sidebar contains a linked data viewer that typically shows the most
recently viewed dataset from the Home: CarSim Run Control library and all of the data
links that are used for that dataset (Figure 52). The area used by the viewer is adjustable.

Figure 52. The CarSim Run Control screen with the Linked Data sidebar.
a.

Adjust the split between the notes and the link viewer with the horizontal double line
(click and drag).

b.

Adjust the width of the sidebar with the vertical double line between the sidebar and
dataset part of the window .

36

Chapter 4

6.

Making New Vehicles

The figure uses red marks to show the connection between the CarSim Run Control dataset
name
and the first item in the viewer
. Blue marks show the connection between the
vehicle link
and the name of the dataset in the viewer
.
The dataset that is currently in view is shown in bold in the link viewer. In this case, it is
CarSim Run Control: Modified Vehicle #1 .

7.

Click on the blue link button for the vehicle assembly

to go to that dataset (Figure 53).
Notice that the Linked Data display now has the second line highlighted in bold
,
indicating that the Vehicle Assembly screen is in view .

Figure 53. The Vehicle Assembly screen.

Datasets that have links to other datasets have a control to expand (+) or collapse (-) the
view. Click on the (+) control for the Vehicle Assembly
to view all of the links used for
this dataset.
If there is not enough room to read a full dataset name in the viewer, hover the mouse over
the name and the full name will pop up, as shown in the figure for the sprung mass
link
that you previously visited by using the blue link .
8.

Notice that the map in the sidebar shows four tire dataset links, as would be expected for a
and , Figure 53). However, the main window has only a single
four-wheeled vehicle (
link to a tire dataset . The tire dataset is used four times in different locations, as specified
with the drop-down control .

37

Chapter 4

Making New Vehicles

The database design in CarSim lets you build the virtual vehicle with parts represented by
datasets. The same dataset can be used repeatedly in different contexts. Click on the blue
link for the tire
to view the tire dataset (Figure 54).

Figure 54.Tire dataset used four times.

9.

Notice that the linked dataset viewer shows all four references to this dataset
and ), confirming that it is used four times in the simulation.

in bold (

The linked dataset viewer not only shows information, but also provides quick access to any
visible dataset. Double click on the name of a dataset to bring it into view. For example,
to bring it into view again.
double-click on the CarSim Run Control item
Review You have seen the major tools in CarSim for navigating through the
database. The Datasets menu lists all of the datasets in the current
library; the Libraries menu lists all of libraries in CarSim; the Go To
menu has commands allowing you to browse different libraries or
datasets; buttons in the upper-left part of the window offer one-click
alternatives to the menus.
The linked dataset viewer in the bottom part of the sidebar shows a
map of all datasets connected to a run; double-click on any one of them
to quickly view the dataset of interest.

Create a Vehicle with Shared Datasets

At the start of this chapter, you duplicated all datasets that contributed to the description of the
baseline vehicle. You then modified two parameters in the sprung mass dataset. In this section,

38

Chapter 4

Making New Vehicles

you will make a third vehicle with two more modified parameters. Because only minor changes
will be made, you will use a much more efficient method to create the new vehicle description.
You should now be viewing the CarSim Run Control dataset named Modified Vehicle #1.
1.

Click the Duplicate button and set the name of the new dataset to Modified Vehicle
#2. (This name should be generated automatically, given that the name of the dataset being
duplicated was Modified Vehicle #1.)

2.

Press the mouse button on the drop-down control adjacent to the blue link for the vehicle
(Figure 55). This time, choose the first item on the menu: [Copy and Link Dataset]
.
You will be prompted to give a name for the new dataset (Figure 56). Change the Category
name to Modification #2 ), define the title as Modified Vehicle #2
, and
click the button Copy and Link .

Figure 55. Run Control dataset for Modified Vehicle #2.

Figure 56. Copy and Link to make a new Vehicle dataset.

3.

Click the blue link for the new vehicle dataset

Assembly screen into view (Figure 57).

39

(Figure 55) to bring the Vehicle:

Chapter 4

Making New Vehicles

Figure 57. Copy and Link to make a new Vehicle Sprung Mass dataset.
4.

Press the mouse button on the drop-down control adjacent to the blue link for the vehicle
and choose the first item on the menu: [Copy and Link Dataset].
(Rigid) sprung mass
When prompted, set the category to Modification #2 and the title to Modified
Sprung Mass #2, and click the Copy and Link button to finish. You should see the
change to match the name you entered:
name of the linked sprung mass dataset
Modified Sprung Mass #2.

5.

Click the blue link for the sprung mass dataset

6.

Edit the wheel center heights for the front wheels to 100

7.

The linked dataset viewer shows the datasets referenced for the run named Modified
Vehicle #2
. It shows that the Vehicle Assembly dataset associated with this run is also
named Modified Vehicle #2
. Click the + button preceding the vehicle dataset to
expand the view to show all datasets linked to the Vehicle Assembly screen. The Sprung
Mass dataset currently in view should appear in bold
. (If not, click the viewer Refresh
button .)

to bring it into view (Figure 58).

to match the rear wheels

In this section of the Quick Start Guide, you have created three new datasets: the new run
, the new vehicle assembly
, and the new sprung mass
. All other properties of the
vehicle are represented with the same datasets that are shared with the modified duplicate
vehicle, Modified Vehicle #1, that was created in the previous section.
Go to the Run Control dataset by double-clicking its name in the dataset viewer
8.

Run the simulation by clicking the Run Math Model button.

40

Chapter 4

Making New Vehicles

Figure 58. Edit Modified Sprung Mass #2.

9.

Change the run color to green and then click the Animate button to compare the modified
vehicle to the baseline (Figure 59). VS Visualizer should show that the green vehicle is lifted
at both axles. Close VS Visualizer when you are done.

Figure 59. View of vehicle lifted at both axles (green) overlaid with the baseline (blue).

41

Chapter 4

Making New Vehicles

10. Update the notes for this run to describe the change made to the vehicle (Figure 60).

Figure 60. Update the notes for the second modification.

Review You have created a second vehicle variant named Modified Vehicle #2.
In this case, you only created three new datasets: (1) a new Run
Control dataset with a link to a new Vehicle Assembly dataset; (2) the
new Vehicle Assembly dataset with a link to a new Vehicle Sprung
Mass dataset, and (3) the new Vehicle Sprung Mass dataset with all
four wheel centers set to a height of 100 mm.
You created the new Vehicle Assembly and Vehicle Sprung Mass
datasets by using the Copy and Link command that is available with
all blue links.

42

5. Managing Data
CarSim keeps vehicle and simulation data organized into libraries of dataset files. In the previous
chapters, you have worked mainly in a small database that you created following the instructions
in this guide. You created new datasets by copying existing ones and making small modifications.
In this chapter, you will look at some more kinds of data in CarSim. You will start by creating a
new dataset from scratch. You will see how to copy datasets from one database to another,
working with more examples from the database installed with CarSim. You will then explore the
CarSim database to see the types of vehicles and test maneuvers that are available as examples.

Make a New Plot Dataset

So far, you have looked at nine plots that were already associated with the double lane change
procedure. The CarSim model calculates about 800 variables that can be plotted; in this section,
you will see how to plot any of them. For the example, we will use the suspension jounce at all
four wheels.
Start the Modified Vehicle #2 dataset from the Run Control screen (Figure 61).

Figure 61. Choose Link to New Dataset for a plot.

Note

The CarSim math models can produce hundreds or even thousands of

output variables for each simulation. It is possible to make new runs with
only subsets of the available variables, saving both file space and time
during post-processing. For the purpose of this tutorial, the checkbox

43

Chapter 5

Managing Data

Write all available outputs

must be checked to ensure that all output
variables are available for plotting.
1.

Use the drop-down control to show more plots

(Figure 61) and choose 1. This will cause
CarSim to display a potential blue link to a plot description
. Until this is linked to a
dataset, it is shown gray with a dimmed title: {No dataset selected}.

2.

Check the box Show only these plots

3.

Press the mouse button on the drop-down control adjacent to the plot link
. Choose the
second item on the menu: [Link to New Dataset]. You will be prompted to give a name for
the new dataset (Figure 62). Leave the category blank
, set the title to Suspension
Jounce , and click the button Create and Link . The link is now blue and shows the
title for the newly created dataset.

Figure 62. Create and Link to a new plot dataset.

3.

Click the blue link for the new plot dataset

(Figure 61) to bring it into view (Figure 63).
As can be seen in the figure, the window has a title, but the field for specifying variables to
plot is empty
(Figure 63).

Figure 63. Dataset to define new plot.

4.

Press the mouse button on the drop-down control adjacent to an unused data link for an
example run
. A menu is shown that includes all of the simulation runs in this database
(there should now be four). Choose any one, e.g., Baseline. After the run is selected
(Figure 64), a blue link appears for the selected run
and information is shown below to
help browse for variables names.

44

Chapter 5

Managing Data

Figure 64. Selecting variables to plot from a browser.

An output file generated for the selected run is read to obtain the names of all variables that
were written and can therefore be used in plots, animations, and post-processing analyses.
The list of all variable names is used to point-and-click to select a pair (X and Y) for
and
) are available to show subsets of the variables;
plotting. Drop-down controls (
other drop-down controls are used to specify whether the variables are identified by short
names or long names (
and
). Given these specifications, a list of variables is shown
for plotting on the Y axis
and another list of variables to select for plotting on the X axis
. Double-click in either selection field (
or
) and the currently selected variable
names are written into the yellow field
that specifies the data channels to be used by
WinEP.

5.

a.

For the X axis, the default variable is Time, which is the first one listed . Make sure
it is selected. This is so easy to find that you do not have to use the drop-down controls
( and ).

b.

For the Y axis, choose Select by type

Choose the option to Show short names

c.

At the bottom of the list of compression variables there are four names: Jnc_L1,
Jnc_L2, Jnc_R1, and Jnc_R2
. For more information, right click and hold while
one of these is selected (Figure 65).

d.

These are the variables we want to plot. Double click on each one; they should then
appear in the yellow field listing variables to plot
(Figure 64).

and then select the type Compression

.

Click the Back button or Home button to return to the CarSim Run Control screen.

45

Chapter 5

Managing Data

Figure 65. Right-click for information about a variable.

6.

Click the Plot button. The plotter shows time histories of the jounce variables from the
original vehicle and the variant called Modified Vehicle #2 (Figure 66). Two things to notice
from these plots are:

Figure 66. Newly defined plot for suspension jounce at each wheel.
a.

The jounce variables from the modified vehicle cover a wider range. This is to be
expected because the modified vehicle sprung mass was lifted and had more roll angle.

b.

The jounce variables start at zero for all wheels for both vehicles. The heights of the
wheel centers shown on the sprung mass screen define the relationships between the
wheel-center height and the sprung mass in the design configuration, which is usually
where jounce is defined as zero. Even though the variant (Modified Vehicle #2) is
lifted, the assumption is that this is the design, so the initial jounce is zero.

After viewing, close WinEP.

Review You created a new plot setup dataset. CarSim scanned an existing
output file to show all of the variables available for plotting, and you
picked several. Although CarSim comes with over 200 plot setups, you
will inevitably want to create at least a few for your own project
applications using the same steps you took here.

46

Chapter 5

Managing Data

Add a Plot to a Procedure Dataset

In the previous section, you created a new plot for one of the simulation examples in your
database. In this section you will modify the procedure so your new plot will be used for all runs
made with the example double lane change procedure.
Start from the Run Control screen, viewing the Modified Vehicle #2 dataset (Figure 67).

Figure 67. Change the number of more plots to zero.

1.

Use the Show more plots control to set the number of more plots back to zero

2.

Click on the blue link for the Procedure

lane change (Figure 68).

to view the Procedure dataset for the double

Figure 68. Add a plot definition to the dataset for the double lane change procedure.
This screen has driver controls, simulation start and stop conditions, road and potentially
other environmental settings, as well as plot definitions associated with the procedure.
Notice that the speed of 120 km/h used in the baseline procedure is set here .

47

Chapter 5

Managing Data

3.

Unlock the dataset, then press the mouse button on the drop-down control adjacent to an
unused data link for a plot
to view a menu of available plot datasets. Choose the dataset
you created: Suspension Jounce . The link should be blue after you make this selection.

4.

Return to the Home screen.

5.

Navigate from the run named Modified Vehicle #2 to the run named Baseline (use the
Datasets menu).

6.

Click the Plot button. You should see one more plot than has been available on previous
occasions where you viewed plots for this run (Figure 69). View the Suspension Jounce plot
to confirm that it shows the four jounce variables. After viewing, close WinEP.

Figure 69. Confirm that there is one more plot associated with this procedure.

Copy Data from One Database to Another

Your Quick Start database started with nine plot datasets, and you added one more. The database
installed with CarSim has hundreds of plot datasets. You dont have to create new datasets if they
already exist in the larger database you can copy them.
1.

Show the CarSim File menu (Figure 70). Near the bottom is a submenu named Recent
Databases. It will show your Quick Start database dimmed, followed by any other databases
that have been used recently with the current version of CarSim. Select the database that was
installed with CarSim (e.g., CarSim82_Data).

48

Chapter 5

Managing Data

Figure 70. Select a recent database.

Note

2.

The default name of the database installed with CarSim is

CarSim[version]_Data, where [version] is the version number (e.g.,
82). Of course, the default is just a suggestion shown when running the
installer; the actual name of the example database is whatever you or the
person installing the software specified at the time.

CarSim will show a dialog box with options to open a new window for the second database,
or to use the same window. Click the New Window button.

Figure 71. Option to open a new window.

3.

You should now have two CarSim windows open (Figure 72). They can be distinguished by
the window titles, which always begin with the database name.

49

Chapter 5

Managing Data

Figure 72. Two CarSim windows.

The database names also appear in CarSim icons in the Window taskbar (at the bottom of
the screen) or when using Windows Alt+Tab to switch between tasks (Figure 73).

Figure 73. CarSim icons in the task bar or task switcher specify the associated database names.
4.

For now, minimize the CarSim window for your Quick Start database (Figure 74).

Figure 74. Minimize the CarSim window for your Quick Start database.
5.

Click the Lib Tool button in the remaining CarSim window (this should be the window for
the main database that was installed with CarSim, Figure 75).

Figure 75. Click the Lib Tool button.

6.

This brings up the Library Tool window (Figure 76). Press the Library selector control
to
browse to the Plot Setup library. There are too many libraries in CarSim to show in a simple
drop-down list, so a scrollable list is shown (Figure 77). Scroll as needed and select the
library named Plot Setup , then click the OK button .

50

Chapter 5

Managing Data

Figure 76. The Library Tool window (initial appearance).

Figure 77. Select the Plot Setup library.

7.

The Library Tool window is now set up to show datasets from the Plot Setup library
(Figure 78). Categories of Plot Setup datasets are shown . Initially, datasets in one of the
categories are listed in the Datasets box
and the Selected Datasets box
is empty.
a.

Click the Add whole library button

. This moves all datasets in the currently
selected library to the Selected Datasets field , as shown in the figure.

b.

Click the button Export to Consolidated Parsfile

. CarSim will prompt you to
choose a location for the file and to give it a name (Figure 79). Be sure that the location
you choose
is somewhere on your computer where you have read and write access.
CarSim will provide a default name
that you can use or change as you see fit. Click
the Save button to export the data .

51

Chapter 5

Managing Data

Figure 78. The Library Tool window, showing dataset from the Plot Setup library.

Figure 79. Specify the name and location for the exported CPAR file.

52

Chapter 5

Managing Data

CarSim will show a progress window for a few seconds and then a Result window
when the export is complete.
c.

Click the Close button for the Library Tool window

(Figure 78).

8.

Minimize the CarSim window for the full database (e.g., CarSim82_Data).

9.

Use the Windows task bar or type Alt+Tab as needed to bring the CarSim window into view
that is associated with your Quick Start database (see Figure 73, page 50).

10. Select the File menu item Import Parsfile (Any Export Type) (see Figure 70, page 49).
CarSim will prompt you to specify a file with a file browser; select the CPAR file you
created in step 7.
Next, CarSim will prompt you with two questions about datasets that might be duplicated.
The first involves support files such as animator shapes and sound files (Figure 80).
Respond by clicking the button Do not overwrite.

Figure 80. Specify Do not overwrite.

The second prompt involves the handling of duplicate datasets (Figure 81). For this
example, the nine plot datasets in the CarSim Quick Start database are probably also in the
CPAR; we want the importing of those files to be skipped.
Choose the default option to keep original names and do not import duplicate datasets
then click the Import button .

Figure 81. Specify do not import duplicate datasets.

CarSim will take about a minute to import the plot datasets and integrate them into the
database. It will show a window displaying the progress, followed by a summary of the
number of datasets imported (Figure 82).

53

Chapter 5

Managing Data

Figure 82. Summary shown when import is completed.

Note

Each plot setup file has at least one support file that specifies the plot
format. It might also have a support file involving data transformations.
Most plot setup files share the same support files and therefore the
support files dont need to be imported repeatedly. Thats why the
message indicates that many datasets were skipped.

11. Go to the Procedures dataset (click on the blue link from the Run Control screen).
12. Press the mouse button on the drop-down control adjacent to an unused plot link
(Figure
83) to see all of the plot options that have been imported. Choose one (e.g., Spring Force
, from the Category submenu Suspension Forces and Moments ).

Figure 83. Choose among the many plot datasets that were imported.

54

Chapter 5

Managing Data

13. Return to the Home screen and click the Plot button to view the new plots. There should be
a plot showing time histories of the four spring forces (or variables specified by whatever
plot setups you added in step 12).
Close WinEP when you are done.
Review You now have two CarSim windows available, each showing a
separate database. You have seen how to transfer data from one to the
other.

Look at a Configurable Function

Many of the CarSim math model equations involve algebraic relationships used to calculate a
variable from values of one or two other variables in the model. These relationships are
represented with configurable functions that can be set at runtime to use various calculation
methods such as table lookup, linear coefficients, or constants. About half of the calculations
performed in a simulation run involve these configurable functions.
1.

Go to the Procedures dataset (Figure 84).

Figure 84. The Procedure screen has a link to a Steering: Driver path follower dataset.
2.

Click on the blue link for a Steering: Driver path follower dataset named Double Lane
Change (Quick Start) . This will bring the path follower dataset into view (Figure 85).
This screen shows a configurable function in which a lateral offset is calculated as a function
of station (longitudinal distance along a path). This information is given in several places:
axis labels for a graphic plot
; the caption above the table of numbers
; and text under
the plot that gives information about identifying data for the function in Echo files .

55

Chapter 5

Managing Data

Figure 85. The target path for the driver model is defined by a table of numbers.
The dataset shown in the figure specifies that the dependent variable (Lateral offset) is
calculated from a table of numbers
using linear interpolation with flat-line extrapolation
. A plot shows the relationship between the two variables .
3.

Unlock the dataset. Click the drop-down control that specifies the function type
to see
the available function types. Change the function type to Constant to see how the screen
changes. Repeat for each of the other types.
When you are through viewing the function type options, click the Undo button
repeatedly until it is dimmed, indicating that the dataset has been restored to its original
state.

4.

Use the Libraries menu to go to the Powertrain: Engine library. This name is part of the
submenu Powertrain. The Powertrain: Engine screen (Figure 86) shows a configurable
function in which an output (engine torque) is calculated from two known variables (engine
speed and throttle position). In this case, the calculation method is specified as 2D linear
interpolation and extrapolation
and the table includes
. Multiple plots are shown
multiple columns, each associated with a different value of throttle position
. To help
adjust the view for the table, a vertical splitter control
can be moved horizontally.

4.

Click the View 3D Map button

at the bottom of the screen for a 3D view of the data
(Figure 87). Use the left mouse button to rotate the view; use Ctrl plus the mouse to zoom.
Exit the viewer (Alt+F4 or close the window) when you are done.

56

Chapter 5

Managing Data

Figure 86. Engine torque is calculated from two variables.

Figure 87. 3D view of engine torque map.

Review Many of the datasets in CarSim involve configurable functions that
define how one variable is calculated from one or two other variables
in the math model. As you gain experience with CarSim, please look in
the VS Browser (GUI and Database) manual (in the Reference
Manuals part of the Help menu) for information about these functions
and the controls used to configure them.

57

Chapter 5

Managing Data

View a Vehicle with Payloads

Up to this point, we have only considered data related to an unloaded vehicle. Before concluding
this tutorial, we will learn how payloads and trailers can be added to the vehicle.
1.

Minimize the CarSim window for your Quick Start database.

2.

Use the Windows task bar or type Alt+Tab as needed to bring the CarSim window into view
that is associated with your full CarSim database.

3.

Use the Libraries menu (Figure 88) to go to the Vehicle: Loaded Condition screen.

Figure 88. Go to the Vehicle: Loaded Condition screen.

4.

With the Vehicle: Loaded Condition screen in view, use the Datasets menu to go to
category Utility Truck and dataset Utility Truck w/Barrels (Figure 89).
The Vehicle: Loaded Condition screen is used to combine motor vehicles with trailers,
payloads, sensor packages, and other datasets that you might use to define a vehicle
condition. For example, Figure 89 shows a utility truck
with three payloads
. The
screen has links for miscellaneous datasets that can also be associated with the vehicle .

58

Chapter 5

Managing Data

Figure 89. Vehicle: Loaded Condition dataset.

This screen is also used for combination vehicles: check the Trailer box
and more links
appear for adding a trailer dataset and associated payloads. (Note that an optional trailer
license is required to run the CarSim math model for vehicles that include trailers.)
5.

You can view a simulation run involving this vehicle combination. To do this, use the Tools
menu and choose the option Find All References to This Dataset (Figure 90). CarSim will
search the current database, and if any other datasets link to the current one, they are listed
in a pop-up window named Dataset References (Figure 91). Double-click on the name of a
dataset to view it.

Figure 90. Tools menu command to find all references to a dataset.

After CarSim brings the Run Control screen into view, click the Close button on the
Dataset References window.

59

Chapter 5

Managing Data

Figure 91. References to the combination vehicle dataset.

Note

6.

The Dataset References window remains visible until you manually

close it. It is sometimes convenient to keep the window in view when
multiple datasets are displayed; this allows quick access to any of them.

Click the Animate button to view the simulation results involving this vehicle. Close VS
Visualizer when you are done.

Browse the Installed Database

You began this tour of CarSim in Chapter 2 by learning to use VS Visualizer and WinEP to view
results for the double lane change in the database installed with CarSim. Now that you have more
experience using the visualization tools and the navigation tools, you should look through the
CarSim database to learn about the types of simulated testing that can be done.
1.

If it is not in view, go to the CarSim Run Control screen by clicking the Home button or
typing Ctrl+H.

2.

Browse through the simulation runs using the Datasets menu and/or the buttons and PgUp
and PgDown keys. Use the Animate and Plot buttons to view existing results for simulation
conditions that you find interesting.

3.

Alternatively, you can browse through the vehicle libraries to find vehicles of interest and
then use the Tools menu command Find All References to This Dataset to locate runs
involving that vehicle, just as you did in the previous section. You might also browse
through the Procedures library to find test scenarios of interest and then use the Tools menu
to locate runs involving the test of interest.
Review You have almost completed the hands-on part of this guide for using
the software. The concluding chapter has just a little more, this time
involving more documentation that is included in CarSim.

60

6. Learning More About CarSim

Now that you have finished the hands-on introduction, you are in a better position to explore
some additional CarSim features.

CarSim Help System

During the tutorial in Chapter 2, you right-clicked buttons for tool tips. You also used the Help
button to see information about the currently displayed data screen.
You will see that much more information is available via the Help menu. It provides reference
information for all menus, controls, and screens (Figure 92). There are also technical memos that
show by example some of the more advanced features in CarSim.

Figure 92. Information available from the Help menu and View button.
All of the documentation has been indexed to provide a rapid search capability. The second item
on the Help menu is Search Help. Select this item to bring up a search window (Figure 93) from
your installed PDF browser (typically Adobe Reader). In the figure, the index file is identified as
CarSim_Help.pdx
and the example search phrase is tire models
. Click the Search
button
to bring up all occurrences of the phrase (Figure 94), and click on any of the results to
view that occurrence in your PDF reader.

61

Chapter 6

Learning More About CarSim

Figure 93. The Search window for PDF files (access with the Help menu item Search Help).

Figure 94. Results of search for a phrase in the CarSim documentation.

Close the PDF viewer when you are done.

62

Chapter 6

Learning More About CarSim

Math Model Documentation

(Figure 95) in the lower-right
On the CarSim Run Control screen, you used the View button
corner to see the Echo files that are produced by the VS Solver programs whenever a run is made.
This control provides access to a number of other machine-generated documents that describe
technical details about the math models.

Figure 95. View button in the lower-right corner of the CarSim Run Control screen.
1.

Use the drop-down list

to select the item Outputs from math model (text)
, then
to see the text file in the editor (Figure 96). The variables are listed in
click View
alphabetical order, based on the unique short names used to identify each variable.

2.

Use the search feature in the text editor to search for Jnc_. (Use the Edit menu item Find
or type Ctrl-F to bring up the search dialog box.) You should find the variables that you
located in the CarSim Plot Setup screen to create a new custom plot (Chapter 5).
Close the text editor when youre done.

63

Chapter 6

Learning More About CarSim

Figure 96. Text file listing all output variables available from a math model.

64

Chapter 6

3.

Learning More About CarSim

If you have Excel or another spreadsheet program on your computer, use the drop-down list
next to the View button (Figure 95) to select the item Outputs from math model
(Excel), then click View . The same information shown before in a text file is now shown
in a spreadsheet. The original sequence is in alphabetical order, as with the text version.
However, the spreadsheet includes other labels such as component, units, and type, and can
be sorted using any of those alternate labels.
For example, Figure 97 shows the names of the output variables sorted by component. The
figure shows how all variables related to suspension are grouped together, making it easier
to find the names of all suspension-related variables available for plotting.
Close the spreadsheet when you are done.

Figure 97. Spreadsheet showing output variables available from a math model.
4.

Use the drop-down list

(Figure 95) to select the item Multibody model description ,
then click View
. This brings up a description of the math model, listing all degrees of
freedom, forces, and moments.
When you are through viewing the text files, close the text editor.

65

Chapter 6

Learning More About CarSim

The CarSim Web Site

If you have Internet access, try the web link near the bottom of the Help menu: Check Web Site
for Updates. If you have not visited this part of the CarSim site before, you will be prompted for
a password (Figure 98).

Figure 98. Login to user section of web site.

CarSim will automatically enter the key ID, so you just have to enter your email address.
Note

Your email is used on the web site only as a password: it is not saved or
recorded.
It will only work if it is listed in the Mechanical Simulation license
database with your other license information. If it doesnt work, contact
Mechanical
Simulation
by
sending
an
email
to
licensecontrol@carsim.com with your key ID and contact information.
Generally, this email address is initially set for the person who bought
the software.

Once logged in, you will see a user section with backup copies of the software, updates, bug
reports, fixes, and other resources that are added as part of normal maintenance.

66

Chapter 6

Learning More About CarSim

What to Read Next

Now that you have learned the basics of using CarSim, there are a few more documents that we
recommend reading as soon as you have time:
1. The VS Browser (GUI and Database) manual (in the Reference Manuals submenu of
the Help menu) gives reference information for the CarSim menus, GUI controls, and the
database.
Note

2.

The VehicleSim (VS) simulation architecture is used in the products

BikeSim, CarSim, and TruckSim. The products share some of the
documentation, and in these cases, the documents use the more generic
VS name.

If you will be working with Simulink, you should read the tech memo Example:
Running with Simulink.

3. The VS Solver Programs manual (in the Reference Manuals submenu of the Help
menu) gives reference information about the solver programs such as input files, output
files, and basic format rules.
4. Details about the vehicle model are covered in Help documents linked to the relevant data
screens. Depending on your interest and expertise, you can read the documentation
concerning the parts of the vehicle that are of greatest interest to you.
Another option for quickly learning about CarSim and its more advanced features is to take a
training course from Mechanical Simulation. This is highly recommended if you are new to
CarSim. The classes expand upon the material learned in this manual by introducing new
examples and teaching many tips for using the software. Please see www.carsim.com for
details. For example, see www.carsim.com/events/ for upcoming webcasts, or subscribe
to our free newsletter at www.carsim.com/forms/newsletter.php.

67

Mechanical Simulation
755 Phoenix Drive, Ann Arbor MI, 48108, USA
Phone: 734 668-2930 Fax: 734 668-2877 Email: info@carsim.com

carsim.com
